3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications
  • 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications
  • 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications
  • 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications
  • 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications
  • 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications
  • 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications
3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications

3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications

Luogo di origine Sichuan, Cina
Marca BONENS
Numero di modello RX20-500W
Dettagli del prodotto
Resistenza:
1Ω-30KΩ
Tolleranza alla resistenza:
±5%, ±5%
Coefficiente di temperatura:
150ppm
Potenza nominale:
10w-5000W
Composizione:
Composizione ceramica
Tipo di pacchetto:
Attraverso il buco
Tipo:
Fisso
Lunghezza:
430 mm
Diametro:
80mm
Valore della resistenza:
1R 2R 3R 4R 6R.......10KR
Intervallo di tolleranza della resistenza:
±1%(F), ±2%(G), ±5%(J), ±10%(K)
Intervallo del coefficiente di temperatura:
≤±250 ppm/℃
Temperatura ambiente:
-55℃～+155℃
tecnologia:
Ferita di filo
Funzione:
Freno/resistenza frenante
Evidenziare:

3000W Wirewound Resistor

,

Aluminum Housed Braking Resistor

,

Ceramic Composition Load Resistor

Termini di trasporto & di pagamento
Quantità di ordine minimo
1
Descrizione di prodotto
Customized 300W Aluminum Housed Wirewound Load Resistor Supply
Product Overview
Green ripple wirewound painted Braking Resistor 3000W designed for industrial applications requiring reliable power dissipation and load testing.
3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 0 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 1 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 2 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 3 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 4 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 5 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 6 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 7
Product Specifications
Product Name Painted Tubular Ceramic Inductive Resistor
Rated Power 3000W
Type Fixed
Size 430mm length & 80mm diameter (Can be customized according to customer requirements)
Color Green
Resistance Value 1R 2R 3R 4R 6R.......10KR
Resistance Tolerance ±1%(F), ±2%(G), ±5%(J), ±10%(K)
Temperature Coefficient ≤±250ppm/℃
Ambient Temperature -55℃～+155℃
Application Load test, equipment discharge, automatic control, frequency converter, etc.
3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 8 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 9 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 10
Key Features
  • High power rating of 3000W for demanding applications
  • Customizable dimensions to fit specific requirements
  • Wide resistance range from 1R to 10KR
  • Multiple tolerance options for precision applications
  • Excellent temperature stability with low coefficient
  • Robust construction for industrial environments
Manufacturer Profile
Professional manufacturer specializing in high-quality industrial resistors and electrical components with extensive experience in custom solutions.
3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 11 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 12 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 13 3000W Aluminum Housed Ceramic Composition Wirewound Braking Resistor for Load Applications 14
