WXD3 13 2W 10 volta potenziometro a filo 4K7 10k
WXD3 13 2W 10 volta potenziometro a filo 4K7 10k
Key Attributes
Marchio:BONENS
Model Number:WXD3-13
Place of Origin:Sichuan, Cina
Standard Packaging:Imballaggio in cartone
Product Summary
Dettagli del prodotto
Evidenziare:
Precisione in 10 giri
,2W 4K7 10K Valutazione
,Elemento Wirewound
Resistance Range:
Da 100Ω a 100kΩ
Tolerance Of Total Resistance:
± 5%
Angle Of Rotation:
3600 ± 20 °C (10 giri)
Voltage Rating:
160v
Torque:
30,5-100 m. N.m.
Powering Rating:
2W (85 °C) 0w (125 °C)
Load Life:
10, 000 settimane
Environmental Temperature:
-55 ~ + 100 °C;
Shaft Type:
L16, L20, L25
Shaft Diameter:
4 mm
Element:
Linea
Terminal:
Saldatura/lato
Taper-Linear:
Tipo di raggi X
Linearity:
1%
Standard Package:
20 per scatola
Type:
Turni multipli
Technology:
Ferita di filo
Turns:
10 giri
Resistance:
4K7, 10K
Power:
2 W
Resistance Range:
Da 100 ohm a 100K ohm
Descrizione di prodotto
Specifiche e Caratteristiche Dettagliate
|
|
|
|
|
|
|
||
|
||
|
||
